产品简介
Product introduction
解决墙面涂料表面长霉的问题！
Solve the problem of mold growth on the wall!
iHeir-TQ水性涂料防霉剂适用于乳胶漆、高分子聚合物乳液、颜料浆及各类水性涂料。亦可用于抑制细菌和真菌在生产和存储印刷水性墨和其它含水有机产品中的滋生。iHeir-TQ已经被广泛用于大容量存储乳液的防霉防腐上。iHeir-TQ为水性漆和涂料的罐內防霉抗菌剂，大量的实验及实际应用证明iHeir-TQ对丙烯酸、聚醋酸乙烯、聚苯乙烯丁酯以及其它共聚物有很好的防霉防腐功能并且与这些产品中的有机和无机物成分有着很好的相容性。
iHeir-TQ environment-friendly coating antifungal (antibacterial) agent is a highly efficient and non-toxic antifungal agent, which is applicable to latex paint, polymer emulsion, water-based pigment paste, and all kinds of coatings. It can also be used to inhibit the growth of bacteria and fungi in the production and the storaging of the printing ink and other aqueous organic products. iHeir-TQ environment-friendly coating antifungal (antibacterial) agent has been widely used in the sterilization for large capacity storage emulsion. The U.S. Environmental Protection Agency (EPA) has approved the registration for iHeir-TQ to become tank fungicide for water-based paint and coatings. A large number of experiments and practical applications have proved that iHeir-TQ has excellent anti-corrosion and sterilizing functions for acrylic acid, polyvinyl acetate, polystyrene butyl esters, and other copolymers, and it has excellent compatibility with organic and inorganic components of these products.
理化指标
Physical and chemical indicators
项目名称 Project Name | 指标 Parameter |
| 活性成分浓度 Concentration of active ingredients | 55% |
| 外观 Appearance | 自然色液体 Natural color liquid |
| pH | 6-7 |
| 粘度（25℃） Viscosity (25 ℃) | 3cps |
| 比重（25℃） Specific gravity (25 ℃) | 1.02g/cm³ |
| 溶解性（水） Solubility (Organic solvent) | 任意比例 It has arbitrary miscibility |
产品特性
Product features
广谱杀菌作用：可同时抑制细菌(包括格兰氏阴性、阳性细菌)和真菌(酵母菌、霉菌等)
成本低：成本(有效使用浓度)比一般市场上的杀菌防腐剂爲低，且使用简便
在建议使用浓度下无毒，并且不含甲醛或甲醛释放物
优异的物理及化学相容性，对成品无副作用
有效活性浓度低，对环境友好
Broad-spectrum sterilizing effect: It can inhibit bacteria (including gram negative and gram positive bacteria) and fungi (yeast, mold, etc.) at the same time
Low costs: The cost (effective using concentration) is lower than the sterilizing preservatives on the general market, and it is easy to use
It is non-toxic under the recommended concentration, and it does not contain formaldehyde or its released substances
It has excellent physical and chemical compatibilities without any side effects on the finished product
Its active concentration is low, which is environment-friendly
毒性和安全操作资料
Toxicity and Safety Operating Data
急性口入毒性：低毒—— 大鼠LD50：3700mg产品/Kg体重
急性皮进毒性：低毒—— 白兔（雌性）LD50：3600mg产品/Kg体重
白兔（雄性）LD50：3500mg产品/Kg体重
皮肤刺激（白兔）未经稀释产品：严重刺激性
稀释使用浓度：无刺激性
皮肤过敏性（天竺鼠）未经稀释产品：皮肤过敏反应
稀释使用浓度：无皮肤过敏反应
环境分解：迅速完全分解成无害物质
环保风险：无害
Acute oral toxicity: Low toxicity – rat–LD50: 3700 mg product/Kg weight
Acute skin toxicity: Low toxicity – white rabbit (female) – LD50:3600 mg product/Kg weight
White rabbit (male) LD50: 3500 mg product/Kg weight
Skin irritation (rabbit) without diluting products: Severe irritation
Diluting concentrations of use: Without irritation
Skin sensitivity (guinea pig) without diluting products: Skin allergic reaction
Diluting concentrations of use: No skin allergic reaction
Environmental decomposition: It can completely decomposed into harmless substances
Environmental risks: Harmless
iHeir-TQ涂料防霉剂抑菌浓度
Minimum inhibitory concentrations (MIC) of bacteria and fungi
| 实验细菌 Test bacteria | 美国标准培养收集所（ATCC）菌种号码 American type culture collection（ATCC）Strain number | 最低抑菌浓度活性成份, ppm Minimum inhibitory concentration of active ingredients, ppm | 实验真菌 Test fungus | 美国标准培养收集所（ATCC）菌种号码 American type culture collection（ATCC）Strain number | 最低抑菌浓度活性成份, ppm Minimum inhibitory concentration of active ingredients, ppm |
| 格兰氏阳性细菌 Gram-positive bacteria | 真菌 Fungus | ||||
| 蜡状芽胞杆菌 Bacillus cereus | RH#L5 | 2 | 交替霉菌属 Alternaria | 11782 | 3 |
| 枯草芽胞杆菌 Bacillus subtillis | RH#B2 | 2 | 小麦霉 Wheat mildew | 16878 | 8 |
| 产胺气杆菌 Aerobacteriu aminogenes | 6871 | 2 | 黑麦霉 Rye mildew | 9642 | 9 |
| 纤维单胞菌类 Fibromonas | 21339 | 6 | 米麦霉 Rice & wheat mildew | 10196 | 5 |
| 卵(藤)黄八叠(球)菌 Oocyte (rattan) yellow octogenum (ball) bacteria | 9341 | 5 | 芽霉菌糠担子霉 Blastomyce mycobasidiomycetes | 9294 | 6 |
| 金黄色葡萄球菌 Staphylococcus aureus | 6538 | 2 | 白色念珠酵母菌 Candida albicans | 11651 | 5 |
| 表皮葡萄球菌 Staphylococcus epidermidis | 155 | 2 | 毛壳霉菌属 Mucor | 6205 | 9 |
| 化脓链球菌 Streptococcus pyogenes | 324 | 9 | 着色分生胞子霉属 Chromophore conidium | 11274 | 5 |
| 白色链球菌 Streptococcus albus | 3004 | 1 | 分生胞子霉属 Conidiospora | 9351 | 8 |
| 格兰氏阴性细菌 Gram-negative bacteria | 胶枝霉属 Rubber branch mildew genera | QM7638 | 9 | ||
| 无色杆菌属 Achromobacter | 4335 | 2 | 香菇多糖霉属 Lentinus polysaccharides | 12653 | 4 |
| 粪产咸菌 Salty bacteria in feces | 8750 | 2 | Lenzties trabea (Geophylum trabeum) | 11539 | 6 |
| 固氮菌属 Azotobacter | 12837 | 5 | Mucor nouxii | RH#L5-83 | 5 |
| 产气肠杆菌 Enterobacter aerogenes | 3906 | 5 | 绳状青霉菌 Cordage penicillium | 9644 | 5 |
| 大肠杆菌 E. coli | 11229 | 8 | 灰绿青霉菌 Cordage penicillium | USDA | 2 |
| 黄杆菌属 Xanthomonas | 958 | 9 | 小綫球状茎点霉属 Nematoglyphus | 6735 | 3 |
| 硝化菌属 Nitrobacter | 14123 | 0.1 | 冬茎点霉属 Wintersweet | 12569 | 2 |
| 亚硝化单胞菌属 Nitrosomonas | 19718 | 0.1 | 产糖芽霉菌 Mold that produces sugar | 9348 | 5 |
| 普通变形杆菌 Bacillus proteus vulgaris | 8427 | 5 | 葡茎根霉菌 Glucomorrhizus | 10404 | 5 |
| 绿脓假单胞菌 Bacillus pyocyaneus | 15442 | 5 | 深红类酵母菌 Dark red yeast | 9449 | 2 |
| 荧光假单胞菌 Pseudomonas fluorescens | 13525 | 2 | 酿酒酵母菌 Saccharomyces cerevisiae | 2601 | 2 |
| 嗜油假单胞菌 Oily pseudomonas | 8062 | 5 | 鬚髮癣菌 Trichophyton mentagrophytes | 9533 | 5 |
| 伤寒沙门氏杆菌 Salmonella typhi | 6539 | 5 | |||
| 宋内氏杆菌 Sonne’s bacillus | 9290 | 2 | |||
产品应用
Product Application
iHeir-TQ涂料防霉剂属于水性体系抗菌产品，可用于水性涂料、水性墨防霉，例如：腻子、乳胶漆、聚乙烯醇及其各种改性物、水溶醇酸树脂、水溶环氧树脂、无机高分子水性树脂。
iHeir-TQ Coating Anti-moldl Agent belonging to the water system antibacterial products, can be used for water-based paint, water-based ink mouldproof, for example: putty, emulsioni paint, polyvinyl alcohol and its various modified content, water soluble alkyd resin, water soluble epoxy resin, inorganic polymer water-based resin.
使用方法及用量
Recommended Using Methods for iHeir-JS
1.iHeir-TQ涂料防霉剂产品的供应形式为液体，易于混合。实验证明iHeir-YQ油漆防霉剂的防霉防腐效果不会因不同的加入点而受到影响。iHeir-TQ可以直接在水性涂料研磨、包装前或使用水性涂料前加入。为确保加入iHeir-TQ涂料防霉剂后的均匀分散，必须将本品和油性涂料充分搅拌（建议按2.0%-3.0%比例添加）。
1.The supply form of iHeir-TQ fungicide is liquid, which is easy to mix. Experiments have proved that iHeir -TQ’s sterilizing and anti-corrosion effects will not be affected by different adding points. iHeir – TQ can be directly added in the process of grinding or paint preparing. To ensure the even disperse after adding iHeir-TQ, emulsion and waterborne paint must be fully mixed (The recommended adding ratio is 2% – 3%).
2.配合微生物胶囊技术加工在包装材料上，其活性成分的浓度取决于产品的大小或空间的大小。
2. Combining with the microbial capsule technology processed in packaging materials, the concentration of the active ingredient depends on the size of the product or the size of the space.
测试iHeir-TQ防霉效果
Test iHeir-TQ mouldproof effect
测试方法介绍:准备两块木板，调配好涂料，使用添加2%的iHeir-TQ涂料防霉剂涂刷到其中一块木板上，使用调好的涂料（未添加iHeir-TQ涂料防霉剂）涂刷到另外一块木板上面，等待干燥，然后准备一个塑料箱子，塑料箱子内装有水，使用砖头垫起来，水平面不要超过砖头，然后将两块涂刷涂料的木板放在砖头上面，将塑料箱子的盖子盖上，放置28天看实验结果，见下图：
Test method is introduced: prepare two boards, allocate a good coating, use the add 2% iHeir – TQ paint coating to one piece on the wood mould inhibitor, using mixed coating (not add iHeir – TQ coating mould inhibitor) besmear to another piece of board above, wait for dry, and then to prepare a plastic box, plastic box containing water, use cushion bricks, water not more than a brick, then put the two pieces of besmear brushs paint board on top of the brick, plastic box lid, 28 days to place to see the results, see below:
左边为添加iHeir-TQ防霉剂的测试结果
On the left is the test result of adding iHeir-TQ anti-mold agent
右边未添加iHeir-TQ防霉剂的测试结果
No test result of iHeir-TQ anti-mold agent added on the right
包装及贮存
Packaging and Storage
25和160公升两种规格，请将iHeir-TQ涂料防霉剂存放在常温室内空气流通处，请勿用无内衬的金属容器来装本品。在普通存储温度下，该产品最少有一年的稳定期。
The product has two specifications–25 & 160 litres. Please put iHeir-TQ in the ventilated area at normal temperature. Please do not use metal container without lining to load iHeir-TQ. Under normal storage temperature, the product’s stability can last at least a year.
